21 products found
APItex-S

APItex-S

  • API 682 Category 1, Type A, Arrangement 1 seal
  • Single seal
  • Balanced
  • Cartridge unit
  • Independent of direction of rotation
  • Solid seal face
  • Solid seat
APItex-T

APItex-T

  • API 682 Category 1, Type A, Arrangement 2 or 3 seal
  • Dual seal in face-to-back arrangement
  • Balanced
  • Cartridge unit
  • Independent of direction of rotation
  • Solid seal faces
  • Solid mating rings
CGSH-KD

CGSH-KD

  • API 682 Category 2 and 3, Type A, Arrangement 3 seal
  • Dual seal in back-to-back arrangement
  • Cartridge unit
  • Independent of direction of rotation
    (with U-grooves)
  • Gas-lubricated
  • Contact free operation, no friction
  • Rotating multiple springs
H75A4-B

H75A4-B

  • API 682 Category 2 and 3, Type A, Arrangement 3 seal
  • Dual seal in back-to-back arrangement
  • Balanced
  • Cartridge unit
  • Rotating multiple springs
  • Integrated pumping device
  • Suitable for pressure reversals
  • Replaces the H75VK seal
H75A4-C

H75A4-C

  • API 682 Category 2 and 3, Type A, Arrangement 2 seal
  • Dual seal in face-to-back arrangement
  • Non-contact outer seal (containment seal)
  • Balanced
  • Cartridge unit
  • Rotating multiple springs
H75A4-T

H75A4-T

  • API 682 Category 2 and 3, Type A, Arrangement 2 and 3 seal
  • Dual seal in face-to-back arrangement
  • Balanced
  • Cartridge unit
  • Rotating multiple springs
  • Integrated pumping device
  • Suitable for pressure reversals
  • Replaces the H75VK seal
H75LG4-C

H75LG4-C

  • API 682 Category 2 und 3, Type A, Arrangement 2 seal
  • Dual seal in face-to-back arrangement
  • Cartridge unit
  • Rotating multiple springs
  • Dry non-contact outer seal (containment seal)
H75VA4-S

H75VA4-S

  • API 682 Category 2 and 3, Type A, Arrangement 1 seal
  • Single seal
  • Balanced
  • Cartridge unit
  • Bi-directional design
  • Rotating multiple springs
  • Integrated pumping device available
  • Replaces the H75VN seal
HRGS-DD

HRGS-DD

  • API 682 Category 2 and 3, Type A, Arrangement 3 seal
  • Dual seal in face-to-back arrangement
  • Gas-lubricated
  • Balanced
  • Cartridge unit
  • Independent of direction of rotation
  • Stationary springs
  • Contact free operation, no friction
LEK777

LEK777

  • API 682 Category 2 and 3, Type A, Arrangement 1 seal
  • Single seal
  • Balanced
  • Cartridge unit
  • Stationary multiple springs
  • Solid seal faces
LL9DJUE

LL9DJUE

  • API 682 Category 2 and 3, Type A, Arrangement 2 seal
  • Dual seal in face-to-back arrangement
  • Dry contact outer seal (containment seal)
  • Balanced
  • Cartridge unit
  • Stationary multiple springs
  • Solid seal faces
LL9DJUU

LL9DJUU

  • API 682 Category 2 and 3, Type A, Arrangement 2 and 3 seal
  • Dual seal in face-to-back arrangement
  • Same size of inboard and outboard seal
  • Balanced
  • Cartridge unit
  • Stationary multiple springs
  • Solid seal faces
LL9DKUU

LL9DKUU

  • API 682 Category 2 and 3, Type A, Arrangement 3 seal
  • Dual seal in back-to-back arrangement
  • Same size of inboard and outboard seal
  • Balanced
  • Cartridge unit
  • Rotating multiple springs
  • Solid seal faces
LL9DSUU

LL9DSUU

  • API 682 Category 2 and 3, Type A, Arrangement 3 seal
  • Dual seal in face-to-face arrangement
  • Same size of inboard and outboard seal
  • Balanced
  • Cartridge unit
  • Stationary multiple springs
  • Solid seal faces
LL9DTUE

LL9DTUE

  • API 682 Category 2 and 3, Type A, Arrangement 2 seal
  • Dual seal in face-to-back arrangement
  • Dry contact outer seal (containment seal)
  • Balanced
  • Cartridge unit
  • Solid seal faces
LL9DTUU

LL9DTUU

  • API 682 Category 2 and 3, Type A, Arrangement 2 or 3 seal
  • Dual seal in face-to-back arrangement
  • Same seal size on inboard and outboard seal
  • Balanced
  • Cartridge unit
  • Rotating multiple springs
  • Solid seal faces
LL9UC

LL9UC

  • API 682 Category 2 and 3, Type A, Arrangement 1 seal
  • Single seal
  • Balanced
  • Cartridge unit
  • Rotating multiple springs
  • Solid seal faces
LNF992

LNF992

  • API 682 Category 2 and 3, Type A, Arrangement 3 seal
  • Dual seal in face-to-back arrangement
  • Gas-lubricated
  • Balanced
  • Cartridge unit
  • Stationary multiple springs
  • Independent of direction of rotation
  • Solid seal faces
